Update Feb 8 2024
fixed unofficial update delete not working
adds fewer entries to the command history
differences from current UU version:
prevents opening more than 1 scene view, but does not close and reopen the scene view, same for the node graph view
allows 1 each of scene view and node graph view, uu allows one or the other
does not use the SetFrameOwnerFrame command since it made the window undockable, window did not behave like other tS window frames
searches the entire windows manager space to see if the window is open, not just the top level
openSceneView2
Code: Select all
// Execute
// Called to execute the command
function Execute(params)
{
//set uufs
if(Node.Exists("Scripts/UUCommands/UUFunctionSet")) {
var sceneViewFS = Node.AccessNearFnSet("Clintons3dView Function Set");
sceneViewFS.UUFS = Node.AccessFnSet("Scripts/UUCommands/UUFunctionSet");
}
var util = System.CreateDO("Clintons3D Package/Utility functions")
//clear the store
var store = "/Scripts/CustomCommands/SceneView/Store";
var subObjCount = Node.SubObjectCount(store);
if(subObjCount > 0) {
for(var i=subObjCount-1; i>=0; i--) {
util.Delete(store + "/"+ Node.SubObject(store,i));
}
}
var selCount = Node.SelectedCount();
//will start blank if nothing is selected - select first scene item
if(Node.SelectedCount() == 0) {
var scene = Space.CurrentScene();
Space.Select(scene + "/" + Node.SubObject(scene, 0));
}
var WMS = WindowsManager.GetWindowsManagerNodeName();
var sceneViewNode = FindNodeByName(WMS, "Clintons3d SceneView Node");
if(sceneViewNode) return;
WindowsManager.CreateWindowFromCLSID('{E9C4FE3C-C3C9-4dfd-8C85-E7F0F81029B4}', '', '', '', 1);//scene view 2
//SetFrameOwnerFrame prevents docking and normal window behavior
//var sceneview2 = WMS + '/' + Node.SubObject(WMS, Node.SubObjectCount(WMS) - 1)
//WindowsManager.SetFrameOwnerFrame(sceneview2, WindowsManager.GetWorkWindow())
if(selCount == 0) {
Space.Unselect();
}
}
function FindNodeByName(currentNode, searchName)
{
if(Node.ShortName(currentNode) == searchName) {
return currentNode;
}
var numsubobj = Node.SubObjectCount(currentNode);
if(numsubobj == 0) return;
for(var i=0;i<numsubobj;i++) {
var subobj = currentNode + "/" + Node.SubObject(currentNode, i);
var thenode = FindNodeByName(subobj, searchName);
if(thenode) {
return thenode;
}
}
}
Code: Select all
// Execute
// Called to execute the command
function Execute(params)
{
//set uufs
if(Node.Exists("Scripts/UUCommands/UUFunctionSet")) {
var sceneViewFS = Node.AccessNearFnSet("Clintons3dView Function Set");
sceneViewFS.UUFS = Node.AccessFnSet("Scripts/UUCommands/UUFunctionSet");
}
var selCount = Node.SelectedCount();
//will start blank if nothing is selected
if(Node.SelectedCount() == 0) {
var scene = Space.CurrentScene();
Space.Select(scene + "/" + Node.SubObject(scene, 0));
}
var WMS = WindowsManager.GetWindowsManagerNodeName();
var graphViewNode = FindNodeByName(WMS, "Clintons3d TemplateView Node");
if(graphViewNode) return;
WindowsManager.CreateWindowFromCLSID('{DD2E0D6B-ED84-4b80-A624-757525B8A591}', '', '', '', 1);//node view window
//SetFrameOwnerFrame prevents docking and normal window behavior
//var nodeview = WMS + '/' + Node.SubObject(WMS, Node.SubObjectCount(WMS) - 1)
//WindowsManager.SetFrameOwnerFrame(nodeview, WindowsManager.GetWorkWindow())
if(selCount == 0) {
Space.Unselect();
}
}
function FindNodeByName(currentNode, searchName)
{
if(Node.ShortName(currentNode) == searchName) {
return currentNode;
}
var numsubobj = Node.SubObjectCount(currentNode);
if(numsubobj == 0) return;
for(var i=0;i<numsubobj;i++) {
var subobj = currentNode + "/" + Node.SubObject(currentNode, i);
var thenode = FindNodeByName(subobj, searchName);
if(thenode) {
return thenode;
}
}
}
